Quake II for old Macs
yquake2 5.11 tuned for seven Macs spanning 1999 to 2019: PowerPC and Intel, one fat binary, KMQuake2 decals and MSAA on top.
A fork of yquake2 5.11 tuned for seven old Macs spanning 1999 to 2019. It's the sister project to QuakeSpasm for old Macs: same machines, same test rack, same trick of bundling four chip-specific builds (G3, G4, G5 and Intel) into one app. On top of the 5.11 base come bullet and blood marks on the walls, edge-smoothing, fog, the underwater wobble, and faster monster animation using AltiVec — mostly ported from KMQuake2 and yquake2 rather than written from scratch. The same app loads different settings on each Mac depending on which model it spots when it starts.
It's a personal project: I love Quake and I collect and tinker with old Macs. My part is the setup and testing — the build, deploy and benchmark scripts, and the per-machine settings. The engine and config changes were made mostly with AI (Claude), which I directed and checked against real benchmarks on the machines.
There's also an Apple Watch companion: a cvar-gated patch streams the player's live health, ammo and objectives off the Mac so the watch can render Quake II's help computer on your wrist. It's off by default and adds nothing to the normal build.
# First build vs current
Two builds on the same machines, both running the same recorded demo (demo1.dm2). The "first build" column is v1.0.0: plain yquake2 5.11 with just enough changes to compile on Lion. The "with features" column is v2.0.0, the build where all the visual features went on (the current release is v2.5.1, which added crisp stencil shadows across the PowerPC machines). The "Floor" column is the lowest frame rate I'll accept on each machine before the game stops feeling smooth.
| Machine | First 640 | Now 640 | Δ | First 1024 | Now 1024 | Δ | Floor |
|---|---|---|---|---|---|---|---|
| imac-2019 | 709.20 | 711.75 | +0% | 701.60 | 726.40 | +4% | 60 ✓ |
| mini-intel | 59.40 | 222.80 | +275% | 80.80 | 100.30 | +24% | 60 ✓ |
| mini-g4 | 126.90 | 100.45 | −21% | 99.15 | 56.80 * | −43% | 60 ✓ |
| sawtooth | 95.00 | 72.90 | −23% | 82.90 | 65.45 | −21% | 60 ✓ |
| quicksilver | 72.40 | 70.70 | −2% | 68.50 | 68.60 | +0% | 60 ✓ |
| yosemite | 65.15 | 46.20 | −29% | 31.60 | 25.20 | −20% | 20 ✓ |
* mini-g4 1024 is the worst observed after hours of continuous benching, thermal degradation on the G4. Cool-machine numbers are around 97 fps. The iMac G5 isn't in this table because it only runs its native 1440×900 (its Leopard driver hangs on a mode switch); there it holds around 47 fps with everything on, a deliberate choice to keep the visuals rather than chase frames.
The big jump is the mini-intel, up 275%, and that came from a single line of code. macOS was making the game wait for the monitor to refresh 60 times a second even though I'd told it not to, which pinned the frame rate at 60. One line (an SDL call telling it not to wait) and the cap was gone.
The drops are the price of the new graphics: decals, fog, the wobble you see underwater, smoother textures, shadows under the monsters and more, all added one at a time. The G3 lost 20–29% because its 1999 graphics chip can only colour in so many pixels a second, and every effect eats into that budget. The same effects barely touch the 2019 iMac, which has power to spare. Every machine still clears its floor. On the G3 the lower number is deliberate: I prefer the richer picture, and it stays playable above its 20 fps floor.
# Get the build
The current release is v2.5.1, which added crisp stencil shadows across the PowerPC machines.
| Bundle | Runs on |
|---|---|
| Quake2-OldMac-v2.5.1.dmg | All seven benched Macs (Panther 10.3.9 → Sequoia 15.7) |
The one universal app runs unchanged on everything from Panther 10.3.9 to Sequoia 15.7. When it launches, macOS picks the right build for that Mac's chip, then the game checks which model of Mac it's on and loads that machine's own settings file from inside the app. It doesn't come with the actual game data (the .pak files), so you bring those from your own copy on Steam, GOG, or an old retail CD.
# The bench
| Machine | Year | CPU | GPU | macOS |
|---|---|---|---|---|
| yosemite | 1999 | PowerMac G3 B&W, 449 MHz | ATI Rage 128, 16 MB | 10.3.9 Panther |
| sawtooth | 1999 | PowerMac G4 AGP, 500 MHz 7400 | NVIDIA GeForce2 MX, 32 MB | 10.4.11 Tiger |
| quicksilver | 2001 | PowerMac G4, 733 MHz 7450 | Radeon 9000 Pro, 64 MB | 10.4.11 Tiger |
| mini-g4 | 2005 | Mac mini G4, 1.25 GHz 7447A | Radeon 9200, 32 MB | 10.4.11 Tiger |
| imac-g5 | 2005 | iMac G5, 2.0 GHz 970FX | Radeon 9600, 128 MB | 10.5.8 Leopard |
| mini-intel | 2007 | Mac mini, 2.33 GHz Core 2 Duo | Intel GMA 950, 64 MB shared | 10.7.5 Lion |
| imac-2019 | 2019 | iMac 27", 3.7 GHz i5-9600K | Radeon Pro 580X, 8 GB | 15.7 Sequoia |
# Architecture
An Ubuntu workstation drives all seven Macs over the network (ssh). The Lion mini is where everything gets built: it holds the compiler toolchains for the G3 (10.3.9 SDK), the G4 (10.4u SDK with AltiVec), the G5 (10.5 SDK) and Lion's Intel chips (x86_64).
Four toolchain passes build four versions of the program, one per chip (G3, G4, G5 and Intel), and Apple's lipo tool glues them into a single universal file inside Quake2.app. No fancy build servers or containers, just rsync, ssh and scp on top of make.
The test loop is the same on every machine: copy the new build over, launch it with timedemo demo1.dm2, read the result out of the log, and write a row to a running spreadsheet tagged with the code version.
# Frames per second across the rack
timedemo demo1.dm2 at commit 00530b6a. Three runs per cell, reported figure is the middle one.
| Machine | 640×480 | 1024×768 | Floor | Settings applied |
|---|---|---|---|---|
| imac-2019 | 711.75 | 726.40 | 60 | everything on (the GPU is never the limit), MSAA |
| mini-intel | 222.80 | 100.30 | 60 | full-res textures, anisotropic filtering, fog, underwater warp, world decals, MSAA |
| mini-g4 | 100.45 | 56.80 | 60 | full-res textures, anisotropic filtering, dynamic lights, fog, underwater warp, world decals, MSAA |
| sawtooth | 72.90 | 65.45 | 60 | full-res textures, anisotropic filtering, light halos, fog, underwater warp, world decals |
| quicksilver | 70.70 | 68.60 | 60 | full-res textures, anisotropic filtering, dynamic lights, fog, underwater warp, world decals, MSAA |
| yosemite | 46.20 | 25.20 | 20 | full-res textures, anisotropic filtering, monster shadows, fog, underwater warp, world decals |
quicksilver sits at about 71 fps at both sizes: that's its screen's refresh rate, and the game is waiting for it rather than being held back by the graphics. So there's still room there for more effects. The iMac G5 isn't in the table because it only runs its native 1440×900, where it holds around 47 fps with everything on.
